E-10
General Guide
*2
Rear Panel
j k l
j SUSTAIN/ASSIGNABLE JACK
k DC 9V jack
l PHONES/OUTPUT jack
664A-E-012A
f Number buttons
g [+]/[–] buttons
• For input of numbers to
change a displayed number
or setting.
• Negative values cannot be
input using the number
buttons. Use [+] (increase)
and [–] (decrease) instead.
h USB port
i VIDEO OUT jack
h i
*1 Attaching the Score Stand
Insert both ends of the music stand provided with the
keyboard into the two holes on the top surface.
m
m MIC jack
e SD CARD SLOT
e
*3
Using the Keyboard Position Stickers
Affix the keyboard position stickers that come with the keyboard as
shown in the illustration below. The locations of the
▼ and ● marks
will correspond to the marks shown in the TV image when you
practice while viewing a TV screen. This will make it easier for you
to see the relationship between the TV image and the keyboard.
C 4 C 5
Affix the keyboard position stickers here.
