Please Note: Always try to sew first
without the walking foot accessory which
should be used only when necessary.
It is easier to guide the fabric and you have a
better view of the seam when using the
standard, regular foot on your machine. Your
sewing machine offers excellent stitch quality
on a wide range of fabrics from delicate
chiffons to multiple layers of denim.
The attachment equalizes the
feeding of the fabric layers. It improves the
matching of plaids, stripes and patterns. It
also helps to prevent uneven feeding of
difficult or napped fabrics, such as velvet or
corduroy.
Lift the presser foot lifter to raise the
presser foot bar.
Remove the presser foot holder by
unscrewing (counterclockwise) the presser
bar attaching screw.
Attach the to the machine as
follows:
-
- Slide the attaching head (c) from left to
right, so that it is fitted onto the presser
foot bar.
- Lower the presser foot bar.
- Replace and tighten (clockwise) the
presser bar attaching screw.
- Make sure both the needle screw and the
presser bar attaching screw are tightly
secured.
Draw the bobbin thread up and place both
the bobbin thread and the needle thread
behind the walking foot attachment.
even feed foot
even feed foot
The fork of the arm (a) should fit around
the needle screw and clamp (b).
2
3
4
1
1
EVEN FEED FOOT
* The is an optional accessory. even feed foot
58
4
2
1
2.5~4.0
a
b
3
