SINGER H74 - Manual (Page 25)

20
CHANGING THE PRESSER FOOT
Attaching the presser foot holder
Attaching the presser foot
Removing the presser foot
Attaching the edge/guilting guide
Raise the presser foot bar (a) by raising
the presser foot lifter. Attach the presser
foot holder (b) as illustrated.
Lower the presser foot holder (b) until
the cut-out (c) is directly above the pin
(d).
Raise the lever (e).
Lower the presser foot holder (b) and
the presser foot (f) will engage
automatically.
Raise the presser foot.
Raise the lever (e) and the foot will
disengage.
The edge/quilting guide (g) can be
attached as illustrated. Adjust as
needed for hems, pleats, quilting, etc.
Turn power switch of off
("O") position when carrying out any
of the operations shown below.
Attention:
1
2
3
4
b
a
d
c
f
b
e
a
e
g
2
3
4
1
