8 •
3.2 Marking on the device and on the rating plate
3.3 Marking on the packaging
4 Lock
• Locks head slide at top of upper telescopic element for
measurement in measuring range 2
• Releases head slide for measurement on lower teles-
copic element (measuring range 1)
5 Head slide
• Locked at top of upper telescopic element
• To be released for measurement on lower telescopic
element (measuring range 1)
6 Read-off line 1 (red)
Reference when head slide is positioned on lower teles-
copic element to measure persons smaller than
130.5 cm (51.4 inch)
7 Read-off line 2 (red)
• Reference when measuring persons taller than
130.5 cm (51.4 inch)
• Results to be read off at upper telescopic element
(here: 155.5 cm)
8 Spacer washer
• A maximum of 5 per screw to allow the measuring rod
to be attached to a wall precisely vertically
• Protruding walls or attachments (e.g. skirting boards or
cable ducts) can be compensated
9 Fixing hole
The fixing screw of the measuring rod is inserted in this
hole
No. Element Function
Text/Symbol Meaning
Model Model number
xx/xx Batch number, engraved on back of device
Observe user manual
Device complies with EC standards and directives
• 0123: Notified body medical products:
TÜV Süd Product Service
0123
Protect from moisture
Arrows indicate top of product.
Transport and store in an upright position.
Fragile
Do not throw or drop.
