NOVEMBER 2001 DIGITAL ANNUNCIATOR DISPLAY DAD104
D5 RING COMMUNICATIONS INC.
DAD104 DIGITAL ANNUNCIATOR DISPLAY
INTRODUCTION
The Digital Annunciator Display (DAD104) provides annunciation of A LARMS , C ALLS and F AULTS for
programmed, supervised stations. Handling is accomplished by single keystrokes. Four 12-
character alpha-numeric D
ISPLAY L INES clearly indicate the annunciated extension numbers and
location description. An audible tone accompanied by the flashing display line alerts the operator to
annunciated events in queue. Auxiliary change over contacts are available to control external audible
alarms or indicator lights which will activate anytime the internal tone is active. Additional
annunciations beyond the view of the four display lines are indicated by the Q
UEUE C OUNTER . The
U P / D OWN scroll buttons are used to maneuver the additional annunciations when more than four
are in the queue into the display area for handling. The current time of day is displayed in 24 hour
format showing hours:minutes:seconds (HH:MM:SS) in the time window.
It's compact size allows for wall or console mounting. The face-plate dimensions match those of
the Ring-Master AA905C, 10" high by 5.5" wide, permitting use of the BBF or BBS863 back box if
necessary behind each unit for a uniform fit and look.
Power to the DAD104 can be supplied from the CB901 central exchange or a remote regulated
24 VDC power supply.
DAD104 operates on Ring Communications' Crisis Alert System together with the DXC901 and the
DNA100. Refer to the N
ETWORK section for network specifications.
LOCATION AND DESCRIPTION OF CONTROLS - See Figure D1
ANSWER KEYS - Respond to incoming signal on a display line.
DISPLAY LINES - Four red dot matrix alpha-numeric display lines, 12 characters long. The first four
digits are always the calling station's call number; the remaining eight characters, including spaces,
are the user defined description of the location. See example on page 6. For systems with a printer
or CRT the description line may be up to 30 characters long not including the four digit call number,
however only the first eight characters will be displayed on the DAD104 display line.
CANCEL KEY - Used to clear the display line and cancel the intercom connection when a call is
complete or to silence the audible tone.
SCROLL KEYS - UP / DOWN - Allow the user to maneuver the display lines for viewing or handling
when there are more than four annunciations in Q
UEUE .
QUEUE COUNTER - A four digit readout that indicates the total number of events in QUEUE.
TIME DISPLAY - Shows the current time of day in 24 hour format HH:MM:SS. The time must be
set through a DNA100 node with a terminal device.
