Crate Amplifiers VC-120H - Manual (Page 8)

Output Power Rating 120W RMS @ 5% THD, 16 ohm load, 120 VAC
Input Impedance 1 M ohm
Maximum Signal Accepted 0dB: 1.5V peak to peak; -6dB: 2.8V peak to peak
Gain Channel A: 68dB
Channel B: 100dB
Tone Control Range Channel A: Treble: 16dB @ 5kHz
Mid: 8dB @ 700Hz
Bass: 10dB @ 50Hz
Mid Boost: 12dB @ 800Hz
Low Boost: 13dB @ 100Hz
Channel B: Treble: 16dB @ 2.5kHz
Mid: 6dB @ 800Hz
Bass: 22dB @ 150Hz
Bright: 10dB @ 3kHz
Mid Boost: 8dB @ 800Hz
Both Channels Presence: 4dB @ 10kHz
Effects Send 2.1V RMS @ full power output
Tube Type Preamp: (1) 12AU7, (4) 12AX7; Power Amp: (4) 6L6GC/EL34
Power Requirements 120VAC, 60Hz, 400VA
100/115VAC, 50/60Hz, 400VA
230VAC, 50/60Hz, 400VA
Size and Weight 12-1/2” H x 27” W x 9-1/2” D, 47 lbs
VC-120H Amplifier
©1998 SLM ELECTRONICS • A division of St. Louis Music • 1400 Ferguson Avenue • St. Louis, Mo 63133
P/N 47-271-02 • 08/98
TECHNICAL SPECIFICATIONS:
The VC-120H is covered with a durable black Tolex ® material. To keep the cabinet in top condition, wipe
it clean with a damp lint-free cloth to remove dirt and road film. Never spray cleaning agents directly
onto the cabinet, and stay away from abrasive cleansers which could damage the finish.
Crate continually develops new products, as well as improves existing ones. For this reason, the specifications and information in this manual are subject to change without notice.
www.crateamps.com
