9
The numbers in parentheses indicate the pages where each item is explained.
.
Camera
.
Charger Unit
General Guide
4 2 1 3
6 7
5
ck cl
bn bm
bo
8 9 bk bl
bq br bs bt
bp
[ ]
[ ]
[ ] [ ]
[SET]
1 Zoom controller
(pages 23, 46, 88, 89)
2 Shutter button (page 23)
3 [ON/OFF] (Power)
(page 21)
4 Microphone
(pages 52, 105)
5 Front lamp
(pages 43, 74)
6 Lens
7 Flash (page 35)
8 [AUTO] button (page 23)
9 ½
(Make-up/
Landscape)
(pages 48, 49)
bk [r] (REC) button
(pages 21, 23)
bl Back lamp
(pages 21, 24, 35)
bm [0] (Movie) button
(page 51)
bn Connector cover
bo USB/AV port (pages
89, 115, 123, 132)
bp Strap hole (page 2)
bq [SET] button (page 31)
br [BS] button (page 56)
bs [MENU] button
(page 64)
bt Control button
([8] [2] [4] [6])
(pages 28, 31, 35, 64,
149)
ck [p] (PLAY) button
(pages 21, 27)
cl Monitor screen
(pages 10, 149)
Back
cm Battery/memory card slots (pages 15, 19, 159, 160)
cn Tripod hole
Use this hole when attaching to a tripod.
co Speaker
Front
cm cn co
Bottom
1 + - Contacts
2 [CHARGE] Lamp
3 AC jack
3
2 1
