S t o r m M a x R W - 5 0 0 0 TM I N S T A L L A T I O N M A N U A L
Phone: 1-866-OLDCASTLE (653-2278)
Web Address: www.oldcastlebe.com
FRAME FABRICATION










3/8"
2 1/2"
2 1/2"
2 1/2"
3/8"
TOP OF HORIZONTAL
"Q" (.332" DIA.)
DRILL THRU TYP.
RW-5132
(MALE)
RW-5131
(FEMALE)
INSTALL CW-998
BULB GASKET
3/8"
2" 29/32"
3/8"
3/8"
"Q" (.332" DIA.)
DRILL THRU TYP.
2 1/2"
2 1/2"
2 1/2"
3/8"
RW-5136
29/32"
2"
TOP OF HORIZONTAL
