Modern AG Chopper - Manual (Page 11)

Chopperrr - 11
CUSHION ValUE aSSEMBlY
Step 5:
Remove the covers on the valve and screw in the
hoses to the openings. Again the orders does
nor matter.
Step 7:
Attach both quick disconnect couplers to the
end of the 96” hoses.
Step 6:
attach 96” hoses to the opposite end of the
valve. Order does not matter, however you may
need help as hose may ne difficult to screw in.
Step 8:
Screw valve onto 90° weld on plate for security.
(weld not shown)
