25
At a glance
Instrument cluster
Item Page
1 L Left turn signal indica-
tor lamp
53
2 v ESP ® warning lamp 378
3 Speedometer
4 Multifunction display 140
5 l Distance warning
lamp
Warning lamp without func-
tion. It illuminates with the ig-
nition on. It should go out
when the engine is running.
6 K Right turn signal indi-
cator lamp
53
7 Coolant temperature indi-
cator with:
137
• Coolant temperature
warning lamp
377,
398
Item Page
8 Tachometer with: 138
1 Supplemental
Restraint System
(SRS) indicator lamp
380,
409
- Antilock Brake Sys-
tem (ABS) indicator
lamp
374
< Seat belt telltale 71,
379
B Low beam headlamp
indicator lamp
131
A High beam headlamp
indicator lamp
131
9 Main odometer with:
ț Gear selector lever
position 140
ț Program mode 140
Item Page
a Clock with: 153
; Brake warning lamp,
USA only
375
3 Brake warning lamp,
Canada only
ú Engine malfunction in-
dicator lamp,
USA only
376
± Engine malfunction in-
dicator lamp,
Canada only
376
C Roll bar warning lamp
b Fuel display with:
A Fuel reserve warning
lamp
379
c Reset button for:
ț Resetting trip odometer 136
ț Adjusting instrument
cluster illumination 136
ț Confirming new time set-
tings 153
