8
Function Range Resolution Accuracy
400! 0.1! ±(0.8% reading + 4 digits)
4k! 0.001k! ±(0.8% reading + 2 digits)
40k! 0.01k!
400k! 0.1k!
4M! 0.001M!
±(1.0% reading + 2 digits)
Resistance
40M! 0.01M! ±(3.0% reading + 5 digits)
40nF 0.01nF ±(5.0% reading + 7 digits)
400nF 0.1nF ±(3.0% reading + 5 digits)
4µF 0.001µF
40µF 0.01µF
±(3.5% reading + 5 digits)
Capacitance
100µF 0.1µF ±(5.0% reading + 5 digits)
5.000Hz 0.001Hz
50.00Hz 0.01Hz
±(1.5% reading + 5 digits)
500.0Hz 0.1Hz
5.000kHz 0.001kHz
50.00kHz 0.01kHz
500.0kHz 0.1kHz
±(1.2% reading + 2 digits)
5.000MHz 0.001MHz
10.00MHz 0.01MHz
±(1.5% reading + 4 digits)
Frequency
Sensitivity: 0.8V rms min. <100kHz; 5Vrms min > 100kHz.
0.1 to 99.9% 0.1% ±(1.2% reading + 2 digits)
Duty Cycle
Pulse width: 100!s - 100ms, Frequency: 5Hz to 150kHz
-4 to 1382°F 1°F Temp
(type-K)
-20 to 750°C 1°C
±(3.0% reading + 3 digits)
(probe accuracy not included)
-4 to 518°F 1°F Temp
(IR)
-20 to270°C 1°C
±2.0% reading or ±2°C, ± 4 °F
NOTE: Accuracy specifications consist of two elements:
• (% reading) – This is the accuracy of the measurement circuit.
• (+ digits) – This is the accuracy of the analog to digital
converter.
