3. Send the Monitor
SMPTE color bars to the monitor from your edit system, signal
generator, camera,
or video source. They should look like this. Or send color bar from
provided DVD. Color Patterns ‐‐‐ Color Bars
4. Using The Remote hit 9‐1‐1‐ then MENU to enable PWx90 factory menu.
5. Scroll over to the PWx90 using the arrows on the remote menu and select “YCbCr Calibration”
by hitting the Right arrow > on the remote.
(***Note After Flashing, Monitor must be turn off once before Calibration***)
(***Note
Do Not
Change Panel Select or the monitor may display a blank screen***)
6. This is what the NTSC color bars will look like on a correctly calibrated monitor note the plunge
bar in the black section on the lower right is barely visable.
