OHM875VD / OHM1075VD / OHM1575VD

English

CAUTION

Make sure the switch is fully to one side or the other. Do not
attempt to confi gure this switch once the player is in position.

4. Cut a one-inch hole in the headliner along the backside of the ceiling bracket for the

cables to pass through.

Install the ceiling bracket and cables

1. Disconnect and remove the original dome light.

2. Screw the metal mounting plate to the beam or plywood using the six ST4.2 x 16

screws.

Metal mounting plate showing screw positions

Note:

Do not cover the original dome light opening.

Connect cables

1. Pull out the original dome light’s power wire and signal/power cable through the

original dome light opening.

2. Place the rubber gasket on the player.

Placing the rubber gasket on the player
