5. Install Introduction
KOPS-Family - User’s Guide
6
www.kontron.com
5.
Install Introduction
1.
The described KOPS-Family has been designed according to the electronic,
mechanical and thermal specifications of the OPS Standard, (Open Pluggable
Specification), developed by Intel.
2.
Please have a look at the user manual and/or datasheet of your display to
confirm whether an adapter is needed or additional adapters might be
needed.
3.
Please switch off the display, projector completely using the hard on/off
switch or preferred disconnect the equipment fully from the mains, before
inserting the Slot-In PC.
4.
The KOPS-System has to be inserted in the appropriate OPS Slot or Dual
Slot Adapter. (Picture 3A / 3B)
5.
The KOPS-System starts up automatically after turning on the display.
6.
The KOPS-System controls its own fan according to the thermal
circumstances. At low temperatures, and if the CPU workload is low, the
fans may not activate.
7.
This is a normal procedure and not classified as a failure.
8.
If the KOPS-Family is equipped with a WIFI option, please ensure to attach
the antenna to the WIFI connector on the KOPS-System.
