CPCI Backplane PD12: CP6-BP8-P47-STD-SL
RID 24229 PD12, Rev. 01 © 2002 PEP Modular Computers GmbH Page 3
1. Introduction
The specific product description provided with this product documentation is part of the PEP’s
CPCI Backplane manual. For further information, in particular regarding general details as well
as safety and warranty statements, refer to the CPCI Backplane Manual, ID 24229.
2. CP6-BP8-P47-STD-SL Positronic Type
Backplane
The main features of the 6U, 8-slot, Positronic type system slot left backplane CP6-BP8-P47-
STD-SL are described in the following table:
Table 1: Distinctive Features of Backplane CP6-BP8-P47-STD-SL
Feature Specification
Form Factor 6U
Size 202.2*262.05 mm
Number of Slots
8
(System slot is on the left side of this backplane)
Bus Resolution 64 bits
Bus Frequency 33MHz
Rear I/O Connectivity P3 to P5 on all slots
Hot-Swap Capability Yes
Power Supply Connectors
Positronic PCIH47, 47-contact
(Power supply connectors are on the right side of this
backplane.)
Redundant Power Supply Yes
System Management Yes
Flexible Grounding Option Yes
Fan Connector Yes
MSD Connector Yes
Power LED Yes
PS-ON Connector Yes
Reset Function Connector Yes
