COMe-cBTi6R / Pinout List
C65
PEG_RX4+
MCSI2_D0_ P
DP-I
-
-
C66
PEG_RX4-
MCSI2_D0_ N
DP-I
-
-
C67
RSVD
RAPID_SHUTDOWN
I-5
PD 100k
100nF capacitor to GND
C68
PEG_RX5+
Not Connected
nc
-
-
C69
PEG_RX5-
Not Connected
nc
-
-
C70
GND
Power Ground
PWR GND
-
-
C71
PEG_RX6+
Not Connected
nc
-
-
C72
PEG_RX6-
Not Connected
nc
-
-
C73
GND
Power Ground
PWR GND
-
-
C74
PEG_RX7+
Not Connected
nc
-
-
C75
PEG_RX7-
Not Connected
nc
-
-
C76
GND
Power Ground
PWR GND
-
-
C77
RSVD
Reserved for future use
nc
-
-
C78
PEG_RX8+
Not Connected
nc
-
-
C79
PEG_RX8-
Not Connected
nc
-
-
C80
GND
Power Ground
PWR GND
-
-
C81
PEG_RX9+
Not Connected
nc
-
-
C82
PEG_RX9-
Not Connected
nc
-
-
C83
RSVD
Reserved for future use
nc
-
-
C84
GND
Power Ground
PWR GND
-
-
C85
PEG_RX10+
Not Connected
nc
-
-
C86
PEG_RX10-
Not Connected
nc
-
-
C87
GND
Power Ground
PWR GND
-
-
C88
PEG_RX11+
Not Connected
nc
-
-
C89
PEG_RX11-
Not Connected
nc
-
-
C90
GND
Power Ground
PWR GND
-
-
C91
PEG_RX12+
MCSI_GPIO1
NC
-
-
C92
PEG_RX12-
MCSI_GPIO3
I/O 3.3
-
-
C93
GND
Power Ground
PWR GND
-
-
C94
PEG_RX13+
MCSI_GPIO5
I/O 3.3
-
-
C95
PEG_RX13-
MCSI_GPIO7
I/O 3.3
-
-
C96
GND
Power Ground
PWR GND
-
-
C97
RSVD
Reserved for future use
nc
-
-
C98
PEG_RX14+
MCSI_GPIO9
I/O 3.3
-
-
C99
PEG_RX14-
MCSI_GPIO11
I/O 3.3
-
-
C100 GND
Power Ground
PWR GND
-
-
C101 PEG_RX15+
Not Connected
nc
-
-
C102 PEG_RX15-
Not Connected
nc
-
-
C103 GND
Power Ground
PWR GND
-
-
C104 VCC_12V
Main Input Voltage (4.75-20V) PWR 4.75-20V -
-
C105 VCC_12V
Main Input Voltage (4.75-20V) PWR 4.75-20V -
-
C106 VCC_12V
Main Input Voltage (4.75-20V) PWR 4.75-20V -
-
C107 VCC_12V
Main Input Voltage (4.75-20V) PWR 4.75-20V -
-
C108 VCC_12V
Main Input Voltage (4.75-20V) PWR 4.75-20V -
-
C109 VCC_12V
Main Input Voltage (4.75-20V) PWR 4.75-20V -
-
C110 GND
Power Ground
PWR GND
-
-
