COMe-cBT6 / Pinout List
D65
PEG_TX4+
Not Connected
nc
-
-
D66
PEG_TX4-
Not Connected
nc
-
-
D67
GND
Power Ground
PWR GND
-
-
D68
PEG_TX5+
Not Connected
nc
-
-
D69
PEG_TX5-
Not Connected
nc
-
-
D70
GND
Power Ground
PWR GND
-
-
D71
PEG_TX6+
Not Connected
nc
-
-
D72
PEG_TX6-
Not Connected
nc
-
-
D73
GND
Power Ground
PWR GND
-
-
D74
PEG_TX7+
Not Connected
nc
-
-
D75
PEG_TX7-
Not Connected
nc
-
-
D76
GND
Power Ground
PWR GND
-
-
D77
RSVD
Reserved for future use
nc
-
-
D78
PEG_TX8+
Not Connected
nc
-
-
D79
PEG_TX8-
Not Connected
nc
-
-
D80
GND
Power Ground
PWR GND
-
-
D81
PEG_TX9+
Not Connected
nc
-
-
D82
PEG_TX9-
Not Connected
nc
-
-
D83
RSVD
Reserved for future use
nc
-
-
D84
GND
Power Ground
PWR GND
-
-
D85
PEG_TX10+
Not Connected
nc
-
-
D86
PEG_TX10-
Not Connected
nc
-
-
D87
GND
Power Ground
PWR GND
-
-
D88
PEG_TX11+
Not Connected
nc
-
-
D89
PEG_TX11-
Not Connected
nc
-
-
D90
GND
Power Ground
PWR GND
-
-
D91
PEG_TX12+
Not Connected
nc
-
-
D92
PEG_TX12-
Not Connected
nc
-
-
D93
GND
Power Ground
PWR GND
-
-
D94
PEG_TX13+
Not Connected
nc
-
-
D95
PEG_TX13-
Not Connected
nc
-
-
D96
GND
Power Ground
PWR GND
-
-
D97
RSVD
Reserved for future use
nc
-
-
D98
PEG_TX14+
Not Connected
nc
-
-
D99
PEG_TX14-
Not Connected
nc
-
-
D100 GND
Power Ground
PWR GND
-
-
D101 PEG_TX15+
Not Connected
nc
-
-
D102 PEG_TX15-
Not Connected
nc
-
-
D103 GND
Power Ground
PWR GND
-
-
D104 VCC_12V
Main Input Voltage (8.5-20V)
PWR 8.5-20V -
-
D105 VCC_12V
Main Input Voltage (8.5-20V)
PWR 8.5-20V -
-
D106 VCC_12V
Main Input Voltage (8.5-20V)
PWR 8.5-20V -
-
D107 VCC_12V
Main Input Voltage (8.5-20V)
PWR 8.5-20V -
-
D108 VCC_12V
Main Input Voltage (8.5-20V)
PWR 8.5-20V -
-
D109 VCC_12V
Main Input Voltage (8.5-20V)
PWR 8.5-20V -
-
D110 GND
Power Ground
PWR GND
-
-
The termination resistors in these tables are already mounted on the module. Refer to the
design guide for information about additional termination resistors.
