COMe-bSC6 / Product Specification
PEG Configuration
The x16 PCI Express Graphics Port (PEG) is compatible to standard PCI Express devices like Ethernet or RAID controllers.
The COMe-bSC6 supports following PEG Port configuration when used as PCI Express Interface:
» 1Ч16
» 1Ч8
» 1Ч4
» 1Ч2
» 1Ч1
The internal PCI Express controller can be re-configured to support up to 3 PCIe ports. The following port configurations
are available via hardware strap options (customized article):
» 2×8 (lanes #0-7 + #8-15)
» 1Ч8 + 2Ч4 (lanes #0-7 + #8-11 + #12-15)
Storage
onboard SSD -
SD Card support -
IDE Interface -
Serial-ATA 2x SATA 6Gb/s, 2x SATA 3Gb/s
SATA AHCI NCQ, HotPlug, Staggered Spinup, eSATA, PortMultiplier
SATA RAID 0, 1, 5, 10, MATRIX (QM67 only)
If SATA AHCI or RAID is disabled in setup, the SATA Interface only supports 3Gb/s transfer
rate and Staggered Spin-Up. To configure a RAID enable RAID support in BIOS Chipset/SATA
settings, connect at least two hard drives and enter the RAID Option ROM by pressing
'CTRL'+'I'
Connectivity
USB 2.0 up to 8x USB 2.0
USB 3.0 up to 2x USB 3.0
USB Client -
PCI -
PCI External Masters -
PCI Express 6x PCIe x1 Gen2
Max PCI Express 7x PCIe without USB 3.0
PCI Express x2/x4 configuration YES (Softstrap option)
Ethernet 10/100/1000 Mbit
Ethernet controller Intel® 82579LM (Lewisville)
- Due to internal chipset configuration the Cougar Point only supports up to 4 USB Hubs
- On Type6 modules with USB3.0 legacy support is disabled in POST for the USB 3.0 Ports
0/1
