8. Main Specifications PCIe Medical LAN Card - User’s Guide (Version 1.00)
8.
Main Specifications
PCIe Medical LAN Card (Single) PCIe Medical Dual LAN Card PCIe Medical LAN Card
Chipset 1x Intel® 82574L Ethernet Controller 2x Intel® 82574L Ethernet Controller
LAN Interfaces • one isolated Ethernet 1000Base-T
port as RJ45 female, complying with
the standard IEC60601-1, 2
nd edition,
• unshielded connector;
• two isolated Ethernet 1000Base-T
ports as RJ45 female, complying with
the standard IEC60601-1, 2
nd edition
• unshielded connectors;
LED Indicators 1x LAN status LED 2x LAN status LED
2x LAN speed LED 1x LAN speed LED
BusType PCIe x1 (PCIe Spezification Version 2.0);
One Lane; Data Rate: 250 MByte/s per direction
Data Transfer Rate 10/100/1000 Mb/s
Mechanical Dimension (PCB) Delivered with standard slot bracket attached:
168.15mm (half length) x 68.9mm (half height);
[6.62" (half length) x 2.713 " (half height)]
Weight Max. 74 g (0.163 lbs)
Connectivity Media UTP CAT5, CAT6, CAT7
(This cable must be connected to Ground or Earth on the other end ( refer to
chapter 6.2 “LAN Port/s”)
8.1. Environmental Specifications
Operating temperature / relative
humidity with minimum 1m/s forced air flow:
0°C ... +60 °C / 15-90 % / non condensing;
(32 … 140 °F / 15-90 % / non condensing)
with passive cooling (assembled in vertical position)
0°C … +45°C / 15-90 % / non condensing;
(32 … 113 °F / 15-90 % / non condensing;
Storage / transit temp. / relative
humidity -20 … +70 °C / 15-95 % non condensing
(-4 … 158 °F / 15-95 %) not condensing
Operating and
Storage / Transit altitude -500 … 3000 m (1640.5 … 9843 ft)
Air Pressure 1100 hPa … 700 hPa
