MSM-LP Evaluation Kit
www.kontron.com 4
GPIO / ADC / PWM Demo Application
The evaluation kit contains a demonstration program for the onboard GPIO / ADC and PWM functions. The demo
program shows the usage of the virtual serial port for communication to the onboard microcontroller which controls
these functions. The Windows version of the program is written in C/C++ (Borland C++ builder). The Linux version of
the program is written in C/C++ with Qt. All sources of the demo programs are included on the hard disk. Use the link
on the desktop to start the program.
MSM-LP System uC
GPIO
PWM
ADC
USB
Figure 3: GPIO / ADC / PWM block diagram.
Figure 3: Demo application running under Windows XP.
Figure 3: GPIO / ADC / PWM loopback adapter.
