Introduction
AM4101
Page 1 - 10
ID 1022-5406, Rev. 1.0
P R E L I M I N A R Y
1.5
Technical Specification
Table 1-2: AM4101 Main Specifications
AM4101
SPECIFICATIONS
Processor and Memory
CPU
The AM4101 supports the following microprocessors:
•
Freescale™ MPC8641D processor, 1.0 GHz, 400 MHz platform frequency
•
Freescale™ MPC8641D processor, 1.32 GHz, 528 MHz platform frequency
•
Freescale™ MPC8641D processor, 1.5 GHz, 600 MHz platform frequency
All microprocessors are provided in a 1023 FC-CBGA packaging.
Please contact Kontron for further information concerning the suitability of
other Freescale processors for use with the AM4101.
Memory
Main Memory:
•
Up to 2 GB unbuffered DDR2 SDRAM memory with ECC running at 600 MHz
Cache structure:
•
64 kB L1 on-die full speed processor cache
•
32 kB for instruction cache for each core
•
32 kB for data cache for each core
•
1 MB L2 cache for each core
NetBootLoader (NBL) Flash Memory:
•
Two redundant Firmware NOR Flash chips (2 x 4 MB)
Mass Storage Device:
•
Up to 4 GB NAND Flash via an onboard IDE Flash Controller
Serial EEPROM with 64 kbit
A
M
C Interconne
ction
Gigabit Ethernet
Common Options Region ports 0-1
•
Two Gigabit Ethernet SerDes ports
Front Panel
•
Two Gigabit Ethernet copper ports
PCI Express
Fat Pipes Region ports 4-7
•
One x4 PCI Express interface operating in root complex or endpoint
Serial RapidIO
Fat Pipes Region ports 8-11
•
One x4 Serial RapidIO interface operating in host or agent configuration
Debug Interface
Extended Options Region port 14
•
Reserved for debug port
Serial Interface
Extended Options Region port 15
•
One serial port
Clock Input
Clocks
•
PCI Express clock reference input (FCLKA)
Connectors
Front Panel
Connectors
•
One serial port (SER0) with RS-232-signal level on RJ-45 connector
•
Two Gigabit Ethernet ports on RJ-45 connectors
AMC Card-edge
Connector
•
One 170-pin AMC Card-edge connector
Switches
DIP Switches
•
One DIP switch SW2 consisting of four switches for board configuration
•
One DIP switch SW3 consisting of four switches for Fat Pipes Region
configuration and IPMI FRU data selection
