Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Specifications
The following table provides a summary of specifications for the CHV-TSTAT and
CHV-THSTAT.
CHV-TSTAT and CHV-THSTAT Specifications
SPECIFICATION DETAILS
Power Requirements 2 Watts (24 VAC @ 83mA) Heating or
Cooling System Supplied
Crestron power factor <1Watt (required for Cresnet
communication only)
Default Network ID 2A
Control System Update Files 1,2,3
2-Series Control System Version C2-2004.CUZ or later
CEN/CN-TVAV Version 5.10.13V.UPZ or later
CNMSX-AV/PRO Version 5.07.05X.UPZ or later
CNRACKX/-DP Version 5.07.06W.UPZ or later
ST-CP Version 4.00.49S.UPZ or later
LCD Display 128 x 64 Transflective 2.75 in (6.99 cm)
Screen Viewing Angles Y Dir. (X=0º): +50º (from top) –50º (from
bottom)
X Dir. (X=10º): +50º (from right) –50º
(from left)
Humidity Range 0 – 100%
Auto Setpoint Range (union of heat
and cool setpoint ranges) 38 –-99°F (3 – 37°C)
Heat Only Setpoint Range 38 –- 89°F (3 – 32°C)
Cool Only Setpoint Range 59 –- 99°F (15 – 37°C)
Temperature Measurement Range 0 – 110° (-18 – 43°C)
Firmware Update Files 4
CHV-TSTAT/CHV-THSTAT
Update Files
CHVTSTAT.xx.UPG or later
CHVTHSTAT.x.x.UPG or later
Dimensions and Weight Height: 3.75 in (9.50 cm)
Width: 5.00 in (12.70 cm)
Depth: 1.04 in (2.63 cm)
Weight: 5.80 oz (165 g)
1. The latest versions can be obtained from the Downloads | Software Updates section of the Crestron
website (
www.crestron.com) . Refer to NOTE after last footnote.
2. Crestron 2-Series control systems include the AV2, CP2, CP2E, MP2, MP2E, PAC2, PRO2, and
RACK2.
3. CNX update files are required for either CNMSX-AV/Pro or CNRACKX/-DP. Filenames for CNX
update files have a UPZ extension and ST-CP files are in one EXE or zipped UPZ file. To avoid program
problems, make certain you are using the update file with the correct suffix letter (e.g., S, V, W, X).
4. Filenames for CHV update files have a UPG extension and are in one zipped UPG file. The ‘x’ in the file
name refers to the version number.
NOTE: Crestron software and any files on the website are for Authorized Crestron dealers
only. New users may be required to register to obtain access to certain areas of the
site (including the FTP site).
Operations and Installation Guide – DOC. 8163A Thermostats: CHV-TSTAT and CHV-THSTAT • 3
