Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Five-Wire Heating/Cooling System Connections
CRESTRON ELECTRONICS
Jumper on P4
between pins 1
and 2
1
2
P4
Integrated
Control
Unit
C
G
R
W
Y
TOP
HUM RH
U
RS
R
RS
R
RS1 RS2 24
(C
)
24
(R
)
24
V
Y Z G
NETWORK
RH RC G Y/
Y1
Y2 O B W/
W1
W2
Backplate
Jumper
From RH
to RC
P1
P3
P6
P5
P4
1
2
3
4
Thermostat Circuit Board
Operations and Installation Guide – DOC. 8163A Thermostats: CHV-TSTAT and CHV-THSTAT • 11
