PB-SIO4A Configuration
ID 19958, Rev. 0300 Page 3 - 5 ® PEP Modular Computers GmbH
3.4 Pinouts
3.4.1 PB-SIO4A/Carrier Board Connector ST101
This is a thirty pin, dual row male header connector which provides interfacing between
the PB-SIO4A and CPU side of the carrier board.
Table 3-2: Pinout of Connector ST101
Signal Pin Pin Signal
+5V (Vcc) 30 29 GND
IA1 28 27 ID0
IA2 26 25 ID1
IA3 24 23 ID2
IA4 22 21 ID3
IA5 20 19 ID4
IA6 18 17 ID5
IAS 16 15 ID6
IDS0 14 13 ID7
N/C 12 11 INT
CS 10 9 INTA
DTACK 8 7 RESET
CLK 6 5 R/W
-12V 4 3 +12V
+5V (Vcc) 2 1 GND
