background image

D R A F T — F O R I N

T E R N A L U S E O N L Y

8

www.kontron.com

User Guide

CPS3402

1.3 Technical Specif ication

Table 1: CPS3402 Main Specifications

FEATURES

SPECIFICATIONS

Co

nnect

or

s

10 Gigabit Ethernet

Two 100 Base-TX/1000 Base-T /10GBase-T Gigabit Ethernet interfaces based on the
Intel® X540 10 Gigabit Ethernet controller. The interfaces are implemented as two
front panel RJ-45 connectors with status LEDs, J7 and J8.

CompactPCI Serial

CompactPCI Serial interface on connectors P1 and P2:

» Compliant with PICMG® CPCI-S.0 R 1.0 CompactPCI® Serial Specification
» Support for one x8 PCI Express 2.1 interface

One optional CompactPCI Serial connector P6 for increased mechanical stability

Hot

Sw

ap

Hot Swap

Hot swap handle with integrated hot swap switch for shutting down the power sup-
plies in order to safely remove the CPS3402 from the system

LEDs

Front Panel LEDs

Integral Ethernet LEDs:

» ACT /LNK(green):

Ethernet Link/Activity

» SPEED (orange):

1000Base-T Ethernet Speed

» SPEED (green):

10GBase-T Ethernet Speed

» SPEED (off) + ACT (on):

100Base-TX Ethernet Speed

Power Status LEDs:

» Pwr (green):

Power Status of the CPS3402

Ge

ne

ra

l

Mechanical

3U, 4 HP, CompactPCI Serial-compliant form factor

Power Consumption

CPS3402 in idle state (no 10 GbE port connected): approx. 6.0 W
CPS3402 with one 10 GbE port connected:

approx. 10.0 W

CPS3402 with two 10 GbE ports connected:

approx. 13.0 W

Power Supply

+12V DC in accordance with the CompactPCI® Serial Specification

Temperature Range

Operational:

0°C to +60°C

Standard

-40°C to +85°C

Extended

Storage:

-40°C to +85°C

Recommended Airflow

Volumetric Flow Rate: > 5 cfm
Sufficient airflow must be provided to ensure optimal operation and long-term
reliability of the CPS3402.

Climatic Humidity

93% RH at 40 °C, non-condensing (acc. to IEC 60068-2-78)

Dimensions

100 mm x 160 mm

Board Weight

277 grams
