Cary Audio Design SLP-88 Preamplifier Operations Manual
- 4 -
FRONT PANEL FEATURES
Power Switch: Rotary 2 position: off/on controls the AC line voltage
Mute: Terminates the output, also operated via remote hand set
Input Select: 4 position rotary switch controls relay input switching
Tape Monitor: 2-position rotary switch engages tape loop circuit
Headphone: 2-position rotary switch will engage headphone transformers
Listening Level: Motorized volume control, manual or via remote
On LED: Indicates internal power supply is power up
Operate LED: Indication of time delay release (approximately 1 minute)
Mute LED: Lights up when the preamplifier is in mute mode
Tape LED: indication of tape monitor loop in operation
Down LED: Lights up red as remote volume is turned to a lower setting.
Up LED: Lights up blue as the remote volume is turned to a higher setting.
REAR APRON FEATURES
AC Connector: Inlet for the detachable AC power cord, standard IEC plug
AC Fuse: !!VERY IMPORTANT!! ONLY USE 1 AMP Slow Blow FUSE
Remote: Female 2 circuit jack, 12 VDC @400 ma. Functions with power on.
Dual Preamp Output: Connect to the inputs of power amps and/or a powered sub
woofer
Tape Out: Constant output of selected input signal for recording, independent of
volume control setting.
Tape In: This is the tape monitor selected input. For use with recording devices that
employ a monitor system to hear the actual recorded signal. May also be used as an
additional line input or an input for an equalizer or other signal adapting device.
CD, Aux 1, Aux 2 and Tuner: These are inputs requiring line level inputs from source
components. These inputs have wide power bandwidth, flat frequency response.
