1
The gate must be installed in a
structurally sound opening. Never install
between two railings or two stair posts.
Ensure mounting surface (wall, doorframe,
etc.) is strong, rigid and is smooth, clean
and grease free. If mounting onto brick,
drywall or other surfaces, an optional gate
installation kit, wooden board mounted to
the surface or additional hardware may be
necessary to provide a solid, smooth
surface. Measure opening to determine if
extensions are needed. Correct width will
be reached by adjusting all 4 corner
spindles. Each spindle adjusts individually
and may be extended to varying lengths
(up to 1 ¾” each) to allow for molding,
uneven walls, etc. This gate can be used
in a closed doorway. Never use gate at top
of stairs
2 Spindle attachment is different
when using extensions and when not
using extensions. If no extension/s are
used, slide top spindles (a) and bottom
spindles (c) into spindle housing end (b).
Push assembly into gate corners.
3
If using extension/s (see Extension
Placement Guide) insert square extension
tubes (f) into gate ends. Connect extension
bar (g) to one upper extension housing (d)
and one lower extension housing (e).
Push assembly over extension tubes.
There should be no metal showing from
extension tubes. It may be necessary to
apply pressure to tubes to ensure they are
fully inserted into gate ends. Slide top
spindles (a) and bottom spindles (c) into
extension tubes.
U S E R G U I D E G1200/G1201 Extra Tall and Wide Auto Close Gateway
®
4
Installation
1
(a) (b) (b) (a)
(c) (b) (b) (c)
2
3
1
(g)
3
(a) (b) (b) (a)
2
(c) (b) (b) (c)
(f) (d) (a)
(f) (e) (c)
P A R T S P R I C E L I S T A N D M E T H O D O F P A Y M E N T
21
Order amount
Shipping & handling
Total $
$
$
METHOD OF PAYMENT
Please do not send cash
Check/Money Order enclosed (payable to: KidCo, Inc.)
VISA (13 or 16 digits) Mastercard (16 digits)
Mo Yr
Credit card account number Expiration date (required)
Signature of cardholder Date
Please print name of cardholder
Name Daytime phone number
Street address Unit
City State Zip
1013 Technology Way
Libertyville, IL 60048-5349
®
G1200/G1201 Auto Close Gateway
®
Price G1200 G1201
A Top Spindle
B Spindle Housing (4)
C Bottom Spindle
D Upper Extension Housing
E Lower Extension Housing
F Extension Tube-5
1 / 8 ” (2)
G Extension Tube-7 7 / 8 ” (2)
H Extension Tube-10 1 / 2 ” (2)
I Extension Bar
$2.00
$2.00
$2.00
$2.00
$2.00
$2.00
$2.00
$2.00
$7.00
Extra Tall and Wide
SHIPPING AND HANDLING CHARGES
If order includes extension tubes,
bars or spindles add $8.00
All others add $5.00
