The nuts will tighten down and bottom out on the shoulder bolts. The nuts have
“nyloc” and do not require any thread locker. Make sure all hardware is tight.
Relocation of the Rubber Latch
Below is a diagram of the right front aluminum diamond plate. From the edges
of the diamond plate, measure the two (2) specified distances as shown in the
diagram. Find the intersection of these two (2) dimensions and drill a
5
/
16
”
diameter hole through the aluminum diamond plate.
