Thoroughly read and understand the Instructions Manual for the Single
Ride-Up SRL Stand-Up™ Trailer that is included with the retrofit kit.
If you lost or need additional copies of any of the instructions manuals
referenced here, please visit our web site at www.KendonUSA.com or
contact us at 714-630-7144 or [email protected].
Tools Required
• 7
/
32
” Allen Wrench
• 3
/
16
” Allen Wrench
• 9
/
16
” Combination Wrench
• 1
/
2
” Combination Wrench
• 7
/
16
” Combination Wrench
• Phillips Screw Driver
• 1
/
4
" or
3
/
8
” Drive Ratchet
• 5
/
16
” Ø Drill Bit
• Cordless Drill
• Sharpie/Marker
• Tape Measure
Parts List
( 1 ) Ride-Up Rear Section
( 1 ) Outside Left Ramp (Driver’s Side)
( 1 ) Center Loading Ramp
( 1 ) Outside Right Ramp (Passenger’s Side)
( 1 ) 6” Rubber Latch with Mounting Bracket
( 4 )
5
/
16
”-18 Coupler Nuts
( 4 )
5
/
16
” Split Lock Washers
( 4 )
5
/
16
”-18 T-Bolt Assemblies (with washers)
( 2 ) 1” Ø Ramp Pins
( 1 ) Single Ride-Up SRL Trailer Retrofit Kit Installation Instructions
( 1 ) Single Ride-Up SRL Stand-Up™ Trailer Instructions
