Cavity Cartridge
Fuse
Mini-
Fuse
Description
31 10 Amp
Red Headlamp Washer
Relay Control –
If Equipped
32 30 Amp
Pink ENG ASD Control
Feed 1
33 10 Amp
Red ABS MOD/J1962
Conn/PCM
34 30 Amp
Pink ABS Valve Feed
35 40 Amp
Green ABS Pump Feed
36 30 Amp
Pink Headlamp/Washer
Control/Smart
Glass – If Equipped
37 25 Amp
Natural Diesel Fuel
Heater – If Equipped
CAUTION!
• When installing the IPM cover, it is important to
ensure the cover is properly positioned and fully
latched. Failure to do so may allow water to get
into the IPM, and possibly result in an electrical
system failure.
• When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system over-
load. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be
corrected.
VEHICLE STORAGE
If you will not be using your vehicle for more than
21 days, you may want to take steps to preserve your
battery.
7
MAINTAINING YOUR VEHICLE 411
