Cavity Cartridge
Fuse
Mini-
Fuse
Description
16 15 Amp
Lt Blue IGN Run/Acc Dome
Lamp/Sunroof/Rear
Wiper Motor/ACC
Inverter
17 10 Amp
Red IOD Feed Mod-Wcm
18 40 Amp
Green ASD Relay Contact
PWR Feed
19 20 Amp
Yellow PWR Amp 1 & Amp
2 Feed
20 15 Amp
Lt Blue IOD Feed Radio
21 10 Amp
Red IOD Feed Intrus
Mod/Siren –
If Equipped
22 10 Amp
Red IGN RUN Heat/AC/
Compass Sensor
Cavity Cartridge
Fuse
Mini-
Fuse
Description
23 15 Amp
Lt Blue ENG ASD Relay
Feed 3
24 15 Amp
Lt Blue Power Sunroof Feed
25 10 Amp
Red Heated Mirror –
If Equipped
26 15 Amp
Lt Blue ENG ASD Relay Feed
2
27 10 Amp
Red IGN RUN Only ORC
Feed
28 10 Amp
Red IGN RUN ORC/OCM
Feed
29 Hot Car
(No Fuse Required)
30 20 Amp
Yellow Heated Seat –
If Equipped
