Jeep 2009 Wrangler - Owner Manual - Manual (Page 441)

Cavity Cartridge
Fuse
Mini
Fuse
Description
M11 10 Amp
Red (Ignition Off Draw)
IOD-HVAC/ATC,
MW SENSR, Under-
hood Lamp (UH
LMP)
M12 30 Amp
Green Amplifier (AMP)
M13 20 Amp
Yellow Ignition Off Draw—
Cabin Compartment
Node (IOD-CCN),
Wireless Control
Module (WCM), SI-
REN, Multifunction
Control Switch (MUL-
TIFCTN SW)
M14 20 Amp
Yellow Trailer Tow (Export
Only)
Cavity Cartridge
Fuse
Mini
Fuse
Description
M15 20 Amp
Yellow COL MOD, IR SNS,
Heater Ventilation,
Air Conditioning/
Automatic Tempera-
ture Control (HVAC/
ATC), Rear View
Mirror (RR VW MIR),
Cabin Compartment
Node (CCN), Transfer
Case Switch (T-CASE
SW), RUN/ST, Multi-
Function Control
Switch (MULTIFTCN
SW), Tire Pressure
Monitor (TPM), Glow
Plug Module (GLW
PLG MOD) — Export
Diesel Only
7
MAINTAINING YOUR VEHICLE 439
