Cavity Cartridge
Fuse
Mini-
Fuse
Description
28 10 Amp
Red IGN RUN ORC/OCM
Feed
29 Hot Car (No Fuse Re-
quired)
30 20 Amp
Yellow Heated Seats
31 10 Amp
Red Headlamp Washer
Relay Control (If
Equipped)
32 30 Amp
Pink ENG ASD Control
Feed 1
33 10 Amp
Red ABS MOD/J1962
Conn/PCM
34 30 Amp
Pink ABS Valve Feed
35 40 Amp
Green ABS Pump Feed
Cavity Cartridge
Fuse
Mini-
Fuse
Description
36 30 Amp
Pink Headlamp/Washer
Control/Smart Glass
(If Equipped)
37 25 Amp
Natural Diesel Fuel Heater —
If Equipped
CAUTION!
• When installing the IPM cover, it is important to
ensure the cover is properly positioned and fully
latched. Failure to do so may allow water to get
into the IPM, and possibly result in an electrical
system failure.
(Continued)
376 MAINTAINING YOUR VEHICLE
