Cavity Cartridge
Fuse
Mini-
Fuse
Description
13 20 Amp
Yellow Pwr Run/Acc Outlet
RR/Dome Lamp
14 10 Amp
Red IOD CCN
15 40 Amp
Green RAD Fan Relay Bat-
tery Feed
16 15 Amp
Lt Blue IGN Run/Acc Dome
Lamp/Sunroof/Rear
Wiper Motor/ACC
Inverter
17 10 Amp
Red IOD Feed Mod-Wcm
18 40 Amp
Green ASD Relay Contact
PWR Feed
19 20 Amp
Yellow PWR Amp 1 & Amp
2 Feed
Cavity Cartridge
Fuse
Mini-
Fuse
Description
20 15 Amp
Lt Blue IOD Feed Radio
21 10 Amp
Red IOD Feed Intrus
Mod/Siren (If
Equipped)
22 10 Amp
Red IGN RUN Heat/AC/
Compass Sensor
23 15 Amp
Lt Blue ENG ASD Relay Feed
3
24 15 Amp
Lt Blue Power Sunroof Feed
25 10 Amp
Red Heated Mirror (If
Equipped)
26 15 Amp
Lt Blue ENG ASD Relay Feed
2
27 10 Amp
Red IGN RUN Only ORC
Feed
MAINTAINING YOUR VEHICLE 375
