FUSES/INTEGRATED POWER MODULE (IPM)
An Integrated Power Module is located in the engine
compartment near the air cleaner assembly. This center
contains cartridge fuses and mini fuses. A label that
identifies each component may be printed on the inside
of the cover. Refer to “Engine Compartment” in this
section of the owner’s manual for the underhood location
of the Integrated Power Module (IPM).
Cavity Cartridge
Fuse
Mini
Fuse
Description
1 Empty Empty
2 15 Amp
Lt. Blue AWD/4WD ECU
Feed
3 10 Amp
Red CHMSL Brake Switch
Feed
4 10 Amp
Red Ignition Switch Feed
5 20 Amp
Yellow Trailer Tow
Cavity Cartridge
Fuse
Mini
Fuse
Description
6 10 Amp
Red IOD Sw/Pwr Mir/
Ocm Steering Cntrl
Sdar/Hands Free
Phone
7 30 Amp
Green IOD Sense1
8 30 Amp
Green IOD Sense2
9 40 Amp
Green Power Seats
10 20 Amp
Yellow CCN Power Locks
11 15 Amp
Lt Blue Power Outlet
12 20 Amp
Yellow Ign Run/Acc Inverter
13 20 Amp
Yellow Pwr run/Acc Outlet
RR
