Jeep 2007 Grand Cherokee - Manual (Page 400)

Cavity
Cartridge
Fuse
Mini
Fuse
Description
18 20 Amp
Yellow Front Control Module
(FCM) Batt #1
19 20 Amp
Yellow Lt Trailer-Tow Stop/
Turn
20 20 Amp
Yellow Front Control Module
(FCM) Batt #3
21 20 Amp
Yellow Rt Trailer-Tow Stop/
Turn
22 30 Amp
Pink Final Drive Control
Module (FDCM)
MOD
23 50 Amp
Red Radiator Fan
27 15 Amp
Blue Ignition Off Draw
(IOD) #1
28 20 Amp
Yellow Ignition Off Draw
(IOD) #2
Cavity
Cartridge
Fuse
Mini
Fuse
Description
29 10 Amp
Red Occupant Restraint
Controller (ORC) R/S
30 10 Amp
Red Occupant Restraint
Controller (ORC)
R/O
VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days you may want to take steps to protect your battery.
You may:
• Remove fuse #27 in the Intelligent Power Module
labeled Ignition-Off Draw (IOD#1).
• Or, disconnect the negative cable from the battery.
• Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
400 MAINTAINING YOUR VEHICLE
