Cavity Fuse Description
1 20 Amp Yel-
low Park Lights, Skim (Sentry
Key)
2 20 Amp Yel-
low Stop Lights
3 20 Amp Yel-
low Subwoofer System
4 10 Amp Red Door Switch Defeat
5 10 Amp Red Airbag
6 20 Amp Yel-
low Rear Wiper
7 10 Amp Red Back-Up Lights, Rear Win-
dow Defroster Relay, ABS
8 10 Amp Red HEVAC
9 10 Amp Red Airbag
10 10 Amp Red Instrument Cluster
11 10 Amp Red Solenoids, DRL
Cavity Fuse Description
12 10 Amp Red Power Distribution Relays,
Skim (Sentry Key)
13 10 Amp Red Turn Signals
14 10 Amp Red Radio
15 10 Amp Red HBL (Rear Window De-
froster) Switch
16 10 Amp Red Headlamp Aim (Export
Only)
17 25 Amp
Natural Front Wiper
18 20 Amp Yel-
low Cigar Lighter
19 20 Amp Yel-
low Spare
20 20 Amp Yel-
low Spare
