JDC Electronic SA SalinoMADD User Manual
Page 5
5
MADD
Technologies sàrl
–
Avenue des Sports 42 – CH-1400 Yverdon-les-Bains – Switzerland
Tel: +41 24 445 31 16 – Fax: +41 24 445 21 23 – Email: [email protected] – www.madd.ch
F
F
i
i
r
r
s
s
t
t
s
s
t
t
e
e
p
p
s
s
w
w
i
i
t
t
h
h
t
t
h
h
e
e
S
S
a
a
l
l
i
i
n
n
o
o
M
M
A
A
D
D
D
D
Replacing dry cells
The batteries are accessible on the back of the device.
Unscrew the two screws of the battery cover, remove
the old batteries and replace the 4 alkaline dry cells
respecting polarity as indicated inside the housing.
Close the lid.
A set of new cells has a voltage of 6V. This voltage is
displayed in the main menu. When this voltage downs
below 3V, it is necessary to change the batteries. The
autonomy is approximately 30 hours in normal use
with one set of alkaline manganese batteries, type.
AAA, AM3, LR6, Mignon, UM3 etc.
Power on the unit
To switch on the SalinoMADD, just press the button
.
At this time the display on right for 2 seconds. It contains also the
software version, useful for eventual future updating.
Functions of the sensor touches
SalinoMADD possess four function buttons disposed on the front panel:
Switch on the unit.
Confirm the chosen parameters displayed.
Go to the next option. Increase numerical values step by step at the
programming of gauging sites.
Back to the last option. Return to the main menu.
