7
SPECIFICATIONS
Engine: 23HP Kohler
Type: Vertical air cooled V-Twin
Air Cleaner: Paper Element
Lube System: Pressurized with oil filter
Starter: 12-volt electric
Traction Drive: Variable-speed hydraulic pumps with wheel motors on each drive
wheel
Hydraulic Tank: 2 quart capacity, One pint filter, 5W40 full synthetic oil
Cutter Deck;Drive: 48" Belt Driven, folding-fabricated-floating
Clutch: Electric BBC
Deck Lift: Hand lever w/pin lock for height adjustment
Cutting Height: 1-1/2" to 4"
No. of Blades 3, belt-driven, power take-off from engine
Controls: Engine ignition and start switch; throttle; choke; left and right
steering levers; electric blade clutch switch; parking brake; mower
deck lift, mower power folding
Parking Brake: Mechanical linkage attached to the brake handle
Front Caster Wheels: 13 x 5.00 - 6
Tire Pressure: 10-12 psi Rear, 20-25 psi front caster
Drive Wheels: 21 x 7.00 - 10
Frame: 1” x 2" Steel square tube and plate, all welded construction
Seat: Adjustable seat. 4" Adjustment
Fuel Tank: Two 5.0 gallon w/individual shutoff valves
Ground Speed: 0-8 MPH forward. 0-4 MPH reverse
Instrumentation Hour meter, Tachometer, Maintenance-minder
Net Weight: 778 lbs w/48" deck
