Page 2
Server Setup Guide
930288A
CyberData Corporation
2
1.0 Setup Diagram
is a setup diagram for a single Intercom configuration. In this configuration, the Intercom
acts as a standalone SIP telephony device.
Figure 1. Setup Diagram
IP Phone
IP Address:___________________
CyberData VoIP Intercom
Server
IP Address:___________________
NetGear EtherFast FS108P Fast Ethernet Switch
