4. For a quick summary of all of the necessary settings on the SIP Setup page (
), see
. For a step-by-step description of the necessary settings, go to
.
Note
If a setting parameter is not listed in
, then your input for that setting
parameter is not required.
5. On the SIP Setup page (
), complete the following steps:
•
In the SIP Server field, type the address of the VCX server.
•
In the SIP User ID field, type the phone extension used in
of
Section 4.1, "VCX Configuration"
.
•
In the Authentication ID field, type the phone extension used in
of
Section 4.1, "VCX Configuration"
.
•
In the Password field, type in the password used in
Section 4.1, "VCX Configuration"
.
•
For SIP Registration, select Yes.
•
For the Unregister on Reboot field, select No.
•
In the Register expiration (minutes) field, type 2.
•
In the Dial-Out Extension field, type an extension number that you want the Intercom to
call.
6. Click on the Save Settings button.
Table 3. SIP Setup Page Settings
SIP Setup Page Items
Setting
SIP Server
Type the address of the VCX.
SIP User ID
Type the phone extension used in
of
Section 4.1, "VCX Configuration"
.
Authentication ID
Type the phone extension used in
of
Section 4.1, "VCX Configuration"
.
Authentication Password
Type in the password used in
of
Section 4.1, "VCX Configuration"
.
SIP Registration
Select Yes.
Unregister on Reboot
Select No.
Register expiration (minutes)
Type 2.
Dial-Out Extension
Type an extension number that you want the Intercom
to call.
Save Settings button
Click on the Save Settings button only after you have
finished configuring all of the settings on the SIP
Setup page.
