Knowing the Design Coffee ADvAnCeD
- GRIND & BREW -
36
1 Bean Hopper Lid
2 250 g Bean Hopper
3 Bean Hopper Locking System seals the base of the bean
hopper for easy removal, storage and transfer of coffee beans.
4 Cleaning Brush for convenient cleaning of the grinding burrs and
coffee grinds chute.
5 Integrated Burr Grinder grinds whole beans just prior to brewing
for maximum freshness, flavour and aroma. Grinder can be turned off
when using pre-ground coffee.
6 12-Cup (1.8L) Water Tank with flip-top lid for convenient, front-
access filling. Grill prevents large debris from entering the tank while
the ‘MAX’ level float rises when the tank is full.
7 Contoured Control Panel with angled design for easy viewing of the
backlit LCD screen.
8 Coffee Grinds Chute delivers ground coffee from the bean
hopper to the coffee basket.
9 Removable Grinds Catcher catches loose grinds from the
coffee grinds chute.
10 Carafe Lid
11 12-Cup Double-Wall, Stainless Steel Thermal Carafe
12 Removable Longlife-Filter
13 Soft Opening, Swing-Out Door with safety interlock system
prevents operation if the coffee basket is not correctly assembled
or the door is not properly closed.
14 Removable Coffee Basket lifts out for easy filling and leaning.
Holds the included Longlife-Filter or paper filters.
15 Steam Baffle assists with water overflow if the coffee basket
becomes blocked.
16 Brew Pause Drip Stop temporarily ceases the flow of coffee
when the carafe is removed so a cup can be poured mid-brew.
17 Drip Tray can be removed for direct brewing into tall cups &
travel mugs.
1
2
3
4
5
7
8
10
12
6
11
9
13
14
15
16
17
