Fotodiox Reflector Arm User Manual
Page 2
1
2
5
in
1 R
efleCtoR
Specs and Features
Product Overview
f
otodiox
P
RemiUm
G
Rade
5
in
1 R
efleCtoR
provides the ultimate in photo
solutions. Use as a fill reflector with a soft cold silver, neutral white or
warm tone gold. Can be used as a plain diffuser or use the black to
block unwanted light. The Fotodiox Premium Grade 5in1 reflector disc
is made of premium grade, quality reflective and diffusive materials
guaranteed to flatten out when opened. A slip-cover with four colors
are enclosed with the diffusive disc: soft gold, black, soft silver, and
soft white. Disc collapses down to about 1/3 of its original size for easy
storage and transportation. This kit includes the Fotodiox 6ft or 8ft Stand
and Fotodiox Telescoping Reflector Holding Arm.
Product Features
• Pro-grade material, heavy duty construction
• Kit with 6ft or 8ft stand and telescoping boom holder
• Collapsible for portability
• 5 applications in one for all photo occasions
• 24 Month manufacture warranty
C
ontents
5 in 1 Reflector Kit Includes
1x Holding Arm
1x Case
1x 5in1 Reflector Set
1x Rotating Heads
1x 6’ or 8’ Stand
The Rotating Heads have four different size holes to fit all
of our holding arms and stands including our boomstands
Each of the heads split an extra inch appart to clamp on
to thicker stands
a
ssemblinG
the
R
efleCtoR
Understanding the Rotating Heads
7/8“
1
”
3/4
“
1
1/8”
29 mm
25 mm
22 mm
19 mm
1
Unfold the stand by loosening
the locking nob and slightly
pulling the legs out
Continue by pushing the leg
lock piece down until legs are
unfolded and steady
NOTE: tighten nob to lock legs
a
ssemblinG
the
R
efleCtoR
The Stand
NOTE: The rotating heads both have all 4 of the different size holes
