Parts List
# Description Part
1 Engine Crankcase
Screw Set (10) EVOG3346408
2 Spark Plug (CM6) EVOG33350
3 Cylinder Head EVOG33103
4 Cylinder Head Gasket (2) EVOG33112
5 Cylinder EVOG33202
6 Piston Ring EVOG33236
7 Piston Set EVOG33214R
8 Piston Pin & Retainer EVOG33213
9 Connecting Rod EVOG33204
10 Prop Washer & Nut EVO108228
11 Drive Hub EVOG33219
12 Front Bearing EVO180109
13 Crankcase EVOG33101
14 Rear Bearing EVOG33110
15 Key EVO400218
16 Crankshaft EVOG33210
17 Back Cover Set EVOG33102
18 Wraparound In-Cowl
Muffler Assembly
EVOG33601
19 Rear Engine Mount EVOG33147
# Description Part
20 Complete Ignition
System
EVOG33300
21 Ignition Sensor &
Mount Bracket EVOG33310A
22 In Line Fuel Filter EVOA105
23 In Tank Fuel Filter/Clunk EVOA106
24 Medium Gas-FPM Fuel
Tubing
EVOA102
25 Carburetor Assembly EVOG33801
26 Carburetor Mount
Gasket Set
EVOG33804
27 Carburetor Insulator EVOG33803
28 Muffler Mounting
Screw Set
EVOG33100A
29 Gasket Set EVOG33416
30 Muffler Gasket Set (2) EVOG33609
31 Carb Mount Bolt Set EVOG33119
32 Throttle & Choke Arm EVOGG33864
NS Carburetor Rebuild Kit EVOG33108A
NS Carburetor Gasket Set EVOG33109A
NS High-Speed/Low-
Speed Needle Set
EVOG33829
