7
40gX evolution engine Dimensions
A
mm
136
F
mm
41
B
mm
118
G
mm
5.3
C
mm
60
H
mm
M10x1
D
mm
84
I
mm
10
E
mm
70
J
mm
46
evolution 40gX
40gX evolution engine Specifications
Bore
Stroke
Displacement
Weight of engine
without ignition*
Weight of ignition unit
RPM range 38mm
35mm
39.7cc/2.42 cu in
1451 g/3.19 lb
190 g/6.7 oz
1400–9500 rpm
Fuel
Break In
Lubrication
unleaded (91 octane)
gasoline
oil with gasoline
in mixture 1:30
oil with gasoline
in mixture 1:40
* The value in the table above stands for the weight of a completely assembled engine, including the spark plug, carburetor,
drive washer and prop screws.
