Specifications BULK CURRENT INJECTION PROBES
14 © ETS-Lindgren, L.P. – February 2005
Rev C – PN 399263
SERIES SPECIFIC ELECTRICAL SPECIFICATIONS
Electrical
Specifications
95236-1 95242-1 95252-1
Frequency
Range
10 kHz to 100 MHz 2 to 400 MHz 10 MHz to 1000 MHz
Maximum Input
Power
100 W 200 W (See Note) 100 W
Maximum Input
Current
20 Amperes 60 Amperes 25 Amperes
Maximum Core
Temperature
80 degrees C 80 degrees C 80 degrees C
Recommended
Maximum
Temperature
Rise
35 degrees C 35 degrees C 35 degrees C
Maximum Time
for Continuous
Rating at Full
Power
30 minutes 30 minutes 15 minutes
Turns Ratio
1:2 1:1 1:1
Inductance
47 µ H, ±20% 0.8 µ H, ±20% 0.5 µ H, ±20%
Table 6
Note:
The power limit of the 95236-1 probe is 100 W. Powers in excess of 75 W should be used with
care to avoid excessive temperature in the equipment under test. Prolonged testing should be
avoided, particularly if unattended.
Note:
The power limit of the 95242-1 probe is 200 W. Powers in excess of 100 W should be used
with care to avoid excessive temperature in the equipment under test. Prolonged testing should be
avoided, particularly if unattended.
Note:
The power limit of the 95252-1 probe is 100 W. Powers in excess of 75 W should be used with
care to avoid excessive temperature in the equipment under test. Prolonged testing should be
avoided, particularly if unattended.
Bulk Injection
Probe
Useful Range Insertion Loss (Typical)
dB Range
95236-1 10 kHz—100 MHz <-15 dB
-35 db ± 3 dB
1 MHz-100 MHz
@ 10 kHz
95242-1 2 MHz—400 MHz <-15 dB 10 MHz – 400 MHz
95252-1 400 MHz—1 GHz <-12 dB
<-22 dB
<-30 dB
400 MHz—700 MHz
750 MHz—900 MHz
950 MHz—1 GHz
Table 7
