Specifications | 11
3.0 Specifications
Electrical Specifications
Model 3164-03 Model 3164-04
Frequency Range: 400 MHz –6 GHz 700 MHz –6 GHz
VSWR (Max):
≤
3.5:1
≤
3.5:1
Gain Over Operating
Frequency:
5 dBi –12 dBi 3 dBi –12 dBi
Maximum
Continuous Power:
200 W 10 W
Impedance
(Nominal):
50 Ω 50 Ω
Cross Polarization
Isolation:
> 25 dB > 20 dB
Dual Polarization
Symmetry:
± 0.1 dB < 2 GHz
± 0.25 dB 2 –6 GHz
± 0.1 dB < 3 GHz
± 0.25 dB 3 –6 GHz
Connector: SMA (2) SMA (2)
Physical Specifications
Model 3164-03 Model 3164-04
Height: 33.0 cm
13.0 in
22.3 cm
8.8 in
Width: 33.0 cm
13.0 in
22.3 cm
8.8 in
Depth: 50.8 cm
20.0 in
35.6 cm
14.0 in
Weight: 9.0 kg
20.0 lb
3.9 kg
8.7 lb
Archived 10/16/12
