Back Panel Connectors
P
OWER
I
NPUT
The input power connection is made through the dual binding post connections.
A properly-rated circuit breaker or switch which removes mains power from the
Model 3725/2M should be installed in proximity to the unit.
RF
G
ROUND
See the description on page 14.
Installation and Application
| 15
