ETS-Lindgren 3725-2M LISN - Manual (Page 11)

3.0 Specifications
Electrical Specifications
Frequency Range: 10 kHz–100 MHz
Network Inductance: 50 µH
Network Impedance: Nominal 50 ohms per
MIL-STD-461F
Current Rating: 25 Amps
Maximum AC Voltage: 250 VAC line-to-ground
Input/Output Connector: Dual binding posts
Environmental
Installation: Indoor use only
Altitude: 4572 m (15000 ft) max
Temperature: 0°C to 40°C (32°F to 104°F)
Relative Humidity: 80% up to 31°C (87.8°F) decreasing
linearly to 50% at 40°C (104°F)
Physical Specifications
Height: 124 mm (4.9 in)
Width: 218 mm (8.6 in)
Depth: 381 mm (15.0 in)
Weight: 5.4 kg (12.0 lb)
Specifications | 11
