Specifications
| 9
3.0 Specifications
Currents higher than the “Maximum Current Input” listed may be used
if the appropriate duty cycles are applied
See table in Appendix B for conversion to Gauss/Ampere
Model 6402
Model 6402M
Type
Mono-axial Mono-axial
Coil Radius
30.5cm
(12.0 in)
30.5cm
(12.0 in)
Turns Per Coil
36 5
Gauge (AWG)
10 20
Coil Factor
(Amperes/Meter/Ampere)
84.3
11.14
Coil Factor
(Gauss/Amperes)
1.06 0.14
R (Ohms DC)
0.5 0.7
L (mH)
3.5 70
Max Continuous Field
(Gauss)
21.2 1.5
Max. Current Input
(Amperes Continuous)
20 10
Self Resonance (kHz)
32 500
Homogeneity
±10% within a
19.8cm cylinder
±10% within a
25.4cm cylinder
Mating Connector
MS3106, A-20-
09S
BNC
